Punch Hole Shutter

Punch Hole Shutter

Ideal for offices, shop fronts, showrooms or where vision and security is a requirement. Punch hole shutters are lightweight and strong with a high level of visibility. They offer protection while still allowing up to 69% vision through the shutter. They’re an excellent choice for shops that still want to make sure their brand is seen and for within buildings. All punch hole shutters can be powder coated in any RAL colour.

A punch hole shutter, also known as a roll-up punch hole shutter or perforated shutter, is a type of security shutter commonly used for commercial spaces such as shops, storefronts, and malls. It is designed to provide both security and visibility for the shop while also allowing air circulation and some level of natural light to enter the premises.

Here are some key features and benefits of punch hole shutters:

  • Punch hole shutters offer a level of security by acting as a physical barrier that helps deter break-ins and vandalism.
  • This is especially important for businesses that want to showcase their products even when the store is closed, or for security personnel to monitor the premises.
  • The perforated design of the shutter allows air to flow into the shop, helping with ventilation. It also allows some natural light to filter through, reducing the need for artificial lighting during the day.
  • Punch hole shutters can be operated manually, using a hand crank or chain mechanism, or they can be motorized for easier opening and closing.

Electric Punch Hole Roller Shutters

Our Electric Roller Shutters (Solid) come with the following features:



  • Galvanised steel roller shutter
  • 75mm solid 22g profiled lath
  • ‘T’ or ‘ L’ profile bottom rail
  • 50 mm x 50 mm steel box section (both sides) used to allow for motor unit and safety brake.

    75 mm x 50 mm box section will be used for shutters over 160 kg in weight (5000 mm x 3200 mm approximately).

  • 50 mm x 75/100 mm angles, where required.

  • Standard guide rails – 65/75/100 mm x 32 mm x 3 mm
  •  Tubular barrel assembly.  Spring assisted barrel assemble for manual shutter
  •  Single Phase 240v tubular motor with emergency override system (Inc crank handle)
  • Safety brake (Doorways only)
  • Galvanised steel pressed canopy (external doors only)
  • Mill finish as standard with Hammerite grey powder coat to steelwork frame only
  • Powder coating available in 200+ Standard RAL colours

All Punch Hole Shutters can be powder coated in any standard RAL colour.
